DALI PHANTOM H-80

DALI PHANTOM H-80

PRODUCT DETAILS The PHANTOM H-80 is the loudspeaker you choose, when large, dynamic and well-defined sound really matters. The sound performance is clear, detailed and yet controlled and powerful. As for the soundstage, it will extend into every corner of even larger rooms. The PHANTOM H series: The DALI PHANTOM H-80 is an in-wall speaker build around traditional loudspeaker technologies. At its centre is the easy to recognize the DALI woofer cone made from a mix of paper pulp and wood fibre. This gives the cone a light, well behaved, but random structure that helps reproduce even the smallest details in the music. The powerful low-loss magnet system deliver precision and timing to the low frequencies and the ultra lightweight soft dome tweeter adds great resolution to the high frequencies. Together they blend into a very coherent, highly detailed, clear and natural soundstage. The PHANTOM H-80 is a true full range speaker and needs no supplement subwoofer – it is all about true hi-fi sound, versatility, and flexibility.

DALI PHANTOM H-80 Product Description

Brand Dali
Product
series
PHANTOM INSTALL SPEAKERS
Frequency
Range (+/-3 dB) [Hz]
46 – 25,000
Sensitivity
(2,83 V/1 m) [dB]
90
Nominal
Impedance [ohms]
6
Maximum
SPL [dB]
109
Recommended
Amplifier Power [W]
30 – 200
Crossover
Frequency [Hz]
2350
High
frequency driver, Quantity
1 x 28 mm
High
frequency driver, Diaphragm type
Soft Textile Dome
Low
frequency driver, Quantity
1 x 8″
Low
frequency driver, Diaphragm type
Wood Fibre Cone
Enclosure
type
Open back
Connection
Input
Single Wire
Recommended
Placement
In-Wall
In-Ceiling
Dimensions
(HxWxD) [mm]
335 x 335 x 106
Cut-Out
Dimensions (HxWxD) [mm]
299 x 299
Weight
[kg]
3.3
Recommended
Volume [litre]
15 – 100
Accessories
Included
3mm Allen Key
Cut-Out Template
Logo Badge
Manual
